Products:



IP Storage Area Network



IP Network Attached Storage



The Best Value for a Turnkey iSCSI IP SAN Appliance.



The IP SAN™ appliances are ideal platforms for entry level to mid-range networked storage applications and can be deployed in a tiered environment as either nearline or online solutions.



Based on the Intel® Architecture, the VIP SAN™ series scales from 1TB to 8TB and are pre-loaded with iSCSI software stack, Hot-Swappable RAID Edition SATA II hard disks along with hardware based multiple RAID level protection and the Intel® Xeon Dual-Core Processors.



With an intuitive management software, these simple and cost-effective VIP SAN™ appliances allow even the smallest organizations enjoy the scalability, security, reliability and performance of powerful iSCSI networked storage.



The modular design of the VIP SAN™ appliance provides seamless block-level I/O support for most networked storage applications such as IP DAS, Email,  Database, storage expansion as well as compliancy and remote site replication.






Entry level 1U iSCSI SAN appliances suitable for most IT projects.  SAS based enclosure backplane with redundant 650W power supplies and four hot-swappable enterprise SATA or SAS 3Gbps drives.  Intel Xeon Dual-Core processor, 2GB RAM, dual Gigabit Ethernet and hardware RAID levels 0, 1, 5, 10, 50, 6 and JBOD with Battery Backup Unit. Locking steel bezel included. Enclosure dimensions:  Height 1.7”, Width 17.2” , Depth 25.6”.  Approximate gross weight: < 50 lbs.





VIPS100 - 1.6TB - 4 x 400GB SATA II, 7200 RPM,

   16MB Cache

VIPS105 - 2TB - 4 x 500GB SATA II, 7200 RPM,

   16MB Cache

VIPS110 - 3TB - 4 x 750GB SATA II, 7200 RPM,

   16MB Cache

VIPS150 - 1.2TB - 4 x 300GB SAS, 15,000 RPM,

   16MB Cache




Easy to deploy 2U iSCSI SAN appliances suitable for most IT applications.  SAS based enclosure backplane with redundant 800W power supplies, twelve hot-swappable enterprise SATA or SAS 3Gbps drives.  Intel Xeon Dual-Core processor, 4GB RAM, dual Gigabit Ethernet and hardware RAID levels 0, 1, 5, 10, 50, 6 and JBOD with Battery Backup Unit. Enclosure dimensions:  Height 3.5”, Width 17.2” , Depth 25.6”.  Approximate gross weight: < 62 lbs.



VIPS200 - 4.8TB - 12 x 400GB SATA II, 7200 RPM,

   16MB Cache

VIPS205 - 6TB - 12 x 500GB SATA II, 7200 RPM,

   16MB Cache

VIPS210 - 9TB - 12 x 750GB SATA II, 7200 RPM,

   16MB Cache

VIPS250 - 3.6TB - 12 x 300GB SAS, 15,000 RPM,

   16MB Cache






High-performance 3U iSCSI SAN appliances designed for capacity intensive applications.  SAS based enclosure backplane with redundant 800W power supplies, sixteen hot-swappable enterprise SATA or SAS 3Gbps drives.  Intel Xeon Dual-Core processor, 4GB RAM, dual Gigabit Ethernet and hardware RAID levels 0, 1, 5, 10, 50, 6 and JBOD with Battery Backup Unit. Enclosure dimensions:  Height 5.2”, Width 17.2” , Depth 25.6”.  Approximate gross weight: < 82 lbs.





VIPS300 - 6.4TB - 16 x 400GB SATA II, 7200 RPM,

   16MB Cache

VIPS305 - 8TB - 16 x 500GB SATA II, 7200 RPM,

   16MB Cache

VIPS310 - 12TB - 16 x 750GB SATA II, 7200 RPM,

   16MB Cache

VIPS350 - 4.8TB - 16 x 300GB SAS, 15,000 RPM,

   16MB Cache
